4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive

China Orientland Wire Mesh Products Co., Ltd certification
China Orientland Wire Mesh Products Co., Ltd certification
I'm Online Chat Now

4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive

4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive
4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive 4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive 4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive 4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive

Large Image :  4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive

Product Details:
Place of Origin: ANPING, CHINA
Brand Name: ORIENTLAND
Certification: ISO,SGS
Model Number: ORDB23071901
Payment & Shipping Terms:
Minimum Order Quantity: 1 Units
Price: USD 29-239 per unit
Packaging Details: Wooden Pallet, Iron Pallet
Delivery Time: 20-25days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000units per month
Detailed Product Description
Type: Defensive Barrier Material: Hot Dipped Galvanized Wire, Galfan Wire,
Hole Shape: Square Mesh Wire Diameter: 4mm
Mesh Size: 3"×3"(7.62cm×7.62cm) Helical Wire Dia.: 4mm
Application: Military Defensive, Flood Control Retaining Wall Geotextile Density: 300g/sqm
Geotextile Color: White, Green, Brown, Black Name: 4mm Welded Mesh Perimeter Wall 7ft Tall Defensive Barrier
High Light:

4mm hesco barrier

,

welded mesh hesco barrier

,

7ft tall defence barrier

4mm Welded Mesh Perimeter Wall 7ft Tall Defensive Barrier


Welded Mesh Defensive barriers are strong structures which are composed of welded gabions and non-woven polypropylene geotextile. According to different use environments, the defensive barriers can be made into standard and recoverable types for your choice.


The Bastion Barriers has been fortified by our defensive barriers and our work with the military. From a simple perimeter wall to a complex base infrastructure, our Welded Mesh Barrier products provide rapid expeditionary protection to personnel, equipment and critical assets in any terrain.


Geo textile-lined Welded Mesh Barrier Coated to ASTM A 856 Wires Conform to BS EN 10218-2:2012
Zinc-Aluminum Coating are to be BS EN 10244-2:2009
Geotextile is to be heavy -duty, Non woven, permeable,Polypropylene Fabric.

4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive 0

General Specification of Defensive Barrier
Model Height Width Length Structure
DB1 1.37m(4'6'') 1.06m(3'6'') 10m(32'9'') 5+4cells
DB2 0.61m(2') 0.61m(2') 1.22m(4') 2cells
DB3 1.0m(3'3'') 1.0m(3'3'') 10m(32'9'') 5+5cells
DB4 1.0m(3'3'') 1.52m(5') 10m(32'9'') 5+5cells
DB5 0.61m(2') 0.61m(2') 3.05m(10') 5cells
DB6 1.68m(5'6'') 0.61m(2') 3.05m(10') 5cells
DB7 2.21m(7'3'') 2.13m(7') 27.74m(91'') 4cellsX2+5cells
DB8 1.37m(4'6'') 1.22m(4') 10m(32'9'') 5+4cells
DB9 1.0m(3'3'') 0.76m(2'6'') 9.14m(30') 6+6cells
DB10 2.21m(7'3'') 1.52m(5') 30.5m(100') 5cellsX4
DB11 1.22m(4') 0.3m(12'') 1.22m(4') 2cells
DB12 2.13m(7') 1.06m(3'6'') 33m(108') 5cellsX6
DB1.9 2.74m(9') 1.06m(3'6'') 3.18m(10'5'') 6cells


Mesh Wire diameter: 3mm to 5mm.

Mesh Opening: 2" × 2", 3" × 3", 4" × 4" or custom openings.
Geotextile colors: white, gray, beige sand and army green.
Geotextile density: 200g/sqm, 250g/sqm, 300g/sqm, 350g/sqm, 400g/sqm
Helical Wire Diameter: 3mm, 4mm
Helical pitch: 1", 2"
Joint Pins Wire Diameter: 4mm
Package: Securest bastion barriers are pre-assembled and packed on pallets enclosing spiral joints.
Finish: Electric galvanized, hot dipped galvanized or Alu-zinc coating upon request.



4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive 1

Applications:

  • Blast mitigation walls
  • Ammo compounds
  • Noise abatement barriers
  • Sentry towers
  • Guard posts, both improvised and in kit form
  • Vehicle barriers
  • Entry Control Points
  • Cover from view
  • Protection from ballistics
  • Protection for aircraft (revetments)
  • Protection of adjacent occupants from the accidental discharge of aircraft weapons
  • Protection of living accommodations
  • Provision of bomb shelters
  • Asset protection

4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive 2

Advantages

  • Secure & reliable

Once filled with soil, sand or gravel, Securest forms a solid and strong barrier with exceptional strength and structural integrity to protect personnel and equipment from enemyfire.

  • Convenient usage

Securest bastion barrier can be used in separate cell or some cells joined together by joint pins to suit different needs of your projects. Almost any locally filling material can be used such as soil, sand, gravel, crushed rock and various other granular materials.

  • Labor saving design

Securest can be collapsed and stacked on pallets for easy package, handling and transport, so that it efficiently saves labor cost.

  • Quick & easy assembly

Securest provides the easiest deploy methods - just unfold it and fill it using minimal manpower or commonly available equipment. Previously, sandbag barrier is considered a slow undertaking as a person can only fill about 20 sandbags per hour. Yet our Securest do ten

times the work.



Barrier Installation

1. Unpack the collapsible wire mesh container from package.
2. Unfold the barrier and connect barriers to reach the designed length
3. Fill soil, sand or gravel into the container. The common machine is front end loader.
4. Compact the content
5. Add layers if required.



4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive 3

4mm Welded Mesh Hesco Barrier Perimeter Wall 7ft Tall Defensive 4
