External Works Woven Hexagonal Hole Mesh Gabion Baskets

External Works Woven Hexagonal Hole Mesh Gabion Baskets
External Works Woven Hexagonal Hole Mesh Gabion Baskets
video play

Large Image :  External Works Woven Hexagonal Hole Mesh Gabion Baskets

Product Details:
Place of Origin: HEBEI, CHINA
Brand Name: ORIENTLAND
Certification: ISO9001:2015,SGS
Model Number: ORWG044
Payment & Shipping Terms:
Minimum Order Quantity: 2000 sqm
Price: USD1.06-2.35 per sqm
Packaging Details: Pallet or pressed bundle
Delivery Time: 7-10days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000 sqm per day
Detailed Product Description
Type: Woven Gabion Material: Galfan Wire, High Zinc Coated Wire
Hole Shape: Hexagonal Mesh Wire Diameter: 2.7mm
Selvage Wire Diameter: 3.4mm Binding Wire Diameter: 2.2mm
Mesh Size: 80×100mm Mesh Size Tolerance: +16%, -4%
Application: Flood Control Retaining Wall, River Bank Vation, Slope Protection Gabion Box Dimension: 2m×1m×1m
Sample: Available And Free Product Name: External Works Woven Mesh Gabion Baskets
High Light:

woven mesh gabion baskets

,

external works mesh gabion baskets

,

hexagonal hole woven stainless gabion baskets

External Works Woven Mesh Gabion Baskets


Products Description:

Woven Mesh Gabion Baskets are manufactured from a double or triple twist chain link hexagonal woven wire mesh. The double or triple twisting prevents unravelling in the event of some wires getting cut or damaged.



The pliability and flexibility of the woven mesh makes it extremely flexible and tough and the ideal solution for civil engineering applications typically on poor or uneven ground, where some deformation of the basket is required or expected. The resulting wall also tends to look more natural, giving it a dry stone wall effect. As a result it particularly suits retaining wall applications for river training and coastal defence applications.

External Works Woven Hexagonal Hole Mesh Gabion Baskets 0



Woven Mesh Gabion Baskets or Gabion Cages and es are purpose designed stone filled wire mesh baskets or cages for use as retaining structures. They are also sometimes referred to as just stone filled bastions, stone cages or baskets.



Gabion baskets are an economical, environmental and established solution for structural retaining walls and coastal defences. Designed like for like, gabions are hard to beat on cost and aesthetics when compared to other established retaining wall systems such as reinforced concrete and masonry. This is particularly so for low to medium height retaining walls.



Different twist structure
The gabions can be made into double twisted structure, which has 3 strands. It can also be made into triple twisted structure, which has 5 strands. The double twisted gabion is suitable for the common applications and is more economical than the triple twisted gabion. The triple twisted gabion has higher tensile strength and stability than the other type. It is suitable for the heavy duty applications to defend the high impacts.
              Double twisted structure.
Triple twisted structure.

External Works Woven Hexagonal Hole Mesh Gabion Baskets 1

Gabion Technical Parameter:

Wire dia.(mm) 2.0 2.2 2.4 2.7 3.0 3.4 3.9
Tolerance(mm) 0.05 0.06 0.06 0.06 0.07 0.07 0.07
Min. Zinc coating(g/m2) 215 230 230 245 255 265 275



Gabion specifications:

Mesh Size Tolerance Diameter Length Width Height Diaphragms

80×100mm

100×120mm

+16%/-4% 2.0-3.0mm 1.5 1 0.5 0
1.5 1 1 0
2 1 0.5 0/1
2 1 1 0/1
3 1 0.5 0/2
3 1 1 0/2
4 1 1 0/3

External Works Woven Hexagonal Hole Mesh Gabion Baskets 2

External Works Woven Hexagonal Hole Mesh Gabion Baskets 3



External Works Woven Hexagonal Hole Mesh Gabion Baskets 4

Gabion baskets application:

  • Retaining wall structures
  • River and canal training works
  • Erosion and scour protection; roadway protection; bridge protection
  • Hydraulic structures, dams and culverts
  • Coastal defence and protection works
  • Rockfall and soil erosion protection
  • External Works

External Works Woven Hexagonal Hole Mesh Gabion Baskets 5

Advantages of the Gabion:

  • Flexibility

An outstanding advantage of the gabion is its flexibility. Its double twisted hexagonal mesh construction permits it to tolerate differential settlement without fracture. This property is especially important when a structure is on unstable ground or in an area where scour from waves or currents can undermine it.

External Works Woven Hexagonal Hole Mesh Gabion Baskets 6

  • Strength

The strength and flexibility of the steel wire hexagonal mesh from which gabions and es are made is utilized to withstand and absorb the forces generated by retained earth or flowing water.

External Works Woven Hexagonal Hole Mesh Gabion Baskets 7

  • Permeability

Hydrostatic heads do not develop behind gabion structures because of their permeable nature. Their ability to combine drainage and retention functions make them ideal structures for slope stabilization.

External Works Woven Hexagonal Hole Mesh Gabion Baskets 8

  • Durability

Gabion or is a heavy monolithic gravity unit able to withstand earth thrust. Its efficiency increases instead of decreasing with age since further consolidation takes place as silt and soil collect in the voids and vegetation establishes itself.

External Works Woven Hexagonal Hole Mesh Gabion Baskets 9

  • Economy

Gabion installations are more economical than rigid or semi-rigid structures for a number of reasons.



Woven Mesh Gabion Baskets Packing and truck loading:

External Works Woven Hexagonal Hole Mesh Gabion Baskets 10
