Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls

Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls
Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls

Large Image :  Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls

Product Details:
Place of Origin: ANPING
Brand Name: ORIENTLAND
Certification: ISO
Model Number: ORWG030
Payment & Shipping Terms:
Minimum Order Quantity: 2000 sqm
Price: Negotiable
Packaging Details: Pallet or nude packing
Delivery Time: 7-10days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 sqm per day
Detailed Product Description
Type: Gabion Wire Mesh Material: Hot Dipped Galvanized Wire, Galfan Wire, PVC Coated Wire
Hole Shape: Hexagonal Wire Gauge: 2.0/2.7/3.0/4.0mm
Aperture: 60×80mm, 80×100mm, 100×120mm, 120×140mm Application: Flood Control Retaining Wall, River Bank Renovation, Slope Protection
Box Size: 2m×1m×1m, 1m×1m×1m, 2m×1m×0.5m Sample: Available And Free
High Light:

80×100mm mesh retaining wall

,

Gabion Mattresses

Double Twisted Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls Gabion Mattreses


Products Description:
a) Gabions are defined as double twisted woven wire mesh box shaped baskets, of various sizes and dimensions.
b) The selvedges of the gabion baskets are the thicker perimeter and edge wires to which the wire mesh is secured as to withstand sudden or gradual stress from any direction.
c) Reinforcing wires are the thicker wires incorporated into the netting during fabrication.
d) The internal diaphragms are the internal wire mesh partitions which divide the gabions into cells.
e) Lacing or tie wire is used to assemble and join the gabion units.
f) Connecting wires are the internal wire used to prevent the gabions from bulging.
g) Alternative wire fasteners are ASTM approved wire fasteners used in lieu of lacing wire.

Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls 0

Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls 1


Double Twisted Hexagonal steel wire mesh Galvanized Gabions. Gabions shall be fabricated in such a manner that the sides, ends, lid and diaphragms can be assembled at the construction site into rectangular baskets of the sizes specified and shown in thedrawings.

Gabions shall be of single unit construction: the base, lid, ends, and sides shall be either woven into a single unit or edge of these members connected to the base section of the gabion in such a manner that strength an flexibility at the connecting
point does not compromise the engineered structural design of the gabion. Where the length of the gabion exceeds on an one half its horizontal width, the gabion shall be divided by diaphragms of the same mesh and gauge as the body of the gabion, into
cells whose length does not exceed the horizontal width. The gabion shall be furnished with the necessary diaphragms secured in proper position on the base in such a manner that no additional tying is required at this juncture.

Gabion Technical Parameter:

Wire dia.(mm) 2.0 2.2 2.4 2.7 3.0 3.4 3.9
Tolerance(mm) 0.05 0.06 0.06 0.06 0.07 0.07 0.07
Min. Zinc coating(g/m2) 215 230 230 245 255 265 275



Gabion specifications:

Mesh Size Tolerance Diameter Length Width Height Diaphragms

80×100mm

100×120mm

+16%/-4% 2.0-3.0mm 1.5 1 0.5 0
1.5 1 1 0
2 1 0.5 0/1
2 1 1 0/1
3 1 0.5 0/2
3 1 1 0/2
4 1 1 0/3



Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls 2



Gabion Wire Mesh advantages:
• Strength – possess the strength and flexibility to withstand forces generated by water and earth masses.
• Permeability – Naturally free-draining, which is accomplished by gravity and by evaporation, as the porous structure permits active air circulation through it.
• Ecology – Offer an environmentally-sensitive solution to soil retention slope stabilization. Constructed of natural stone fill, the gabions are naturally porous. This allows interaction between the land and surrounding water table.
• Low Construction Cost – Easy to install, requiring limited equipment, no skilled labor, minimal foundation preparation, no drainage provisions, and low stone fill costs, generally provided by a local stone or rock supplier.



Gabion box application:

Double twisted woven wire mesh gabion baskets filled with stone and used for various applications including but not limited to retaining walls, mechanically stabilized soil retaining structures, stream bank protection, slope paving, outfall structures, weirs, drop structures, etc.

Hexagonal Steel Wire Mesh Galvanized Gabions Retaining Walls 3
