High Strength Hexagonal Wovenmesh Gabion Rolls Rock Netting Fall Protection

High Strength Hexagonal Wovenmesh Gabion Rolls Rock Netting Fall Protection
High Strength Hexagonal Wovenmesh Gabion Rolls Rock Netting Fall Protection High Strength Hexagonal Wovenmesh Gabion Rolls Rock Netting Fall Protection

Large Image :  High Strength Hexagonal Wovenmesh Gabion Rolls Rock Netting Fall Protection

Product Details:
Place of Origin: ANPING
Brand Name: ORIENTLAND
Certification: ISO
Model Number: ORWG021
Payment & Shipping Terms:
Minimum Order Quantity: 2000 sqm
Price: Negotiable
Packaging Details: Pallet or nude packing
Delivery Time: 7-10days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 sqm per day
Detailed Product Description
Type: Gabion Wall Basket Material: Hot Dipped Galvanized Wire, Galfan Wire, PVC Coated Wire
Hole Shape: Hexagonal Wire Gauge: 2.0/2.7/3.0/4.0mm
Aperture: 80×100mm, 100×120mm, 120×140mm Application: Flood Control Retaining Wall, River Bank Renovation, Slope Protection
Box Size: 2m×1m×1m, 1m×1m×1m, 2m×1m×0.5m Sample: Available And Free
High Light:

pvc coated gabion baskets

,

reno gabion mattress

High Strength Durable Hexagonal Wovenmesh Gabion Rolls Rock Netting Fall Protection


Products Description:

Manufactured in Orientland, wovenmesh options of 80x100x2.70mm, and 60x80x2.20mm aperture. With salvage wire of 3.40mm diameter, supplied with 2.20mm binding wire. We supply these materials in standard sized Gabion boxes or mesh rolls. Class A Galvanised, Galfan or with Grey or Green PVC coating.



Hole Size Wire Diameter Salvage Wire Binding Wire
80x100mm 2.70mm 3.40mm 2.20mm
60x80 2.20mm 3.40mm 2.20mm



Hexagonal Wovenmesh Advantages


1, Flexible high strength mesh for use in Gabions
2, Mesh is made with double twist for strength and cannot easily unravel if wire is cut
3, Hexagonal wovenmesh is made to withstand very high compressive loads from above in large retaining walls and fast flowing water velocities in river situations
4, Wire is Class A Galvanised or PVC coated to prevent mesh corrosion on site
5, Wovenmesh is strong and can be used for high strength requirements like rock netting fall protection
6, Wovenmesh is high strength but still flexible enough over poor underlying soil profiles



Hexagonal woven mesh is the perfect product for rockfall mesh netting and to cover large areas of river mattresses quickly. The mesh is of high strength and made of durable flexible material. Two mesh type options are available, either Class A Galvanised or together with a PVC extruded wire coating. The mesh aperture size is either 60×80 or 80x100mm hexagonal mesh type with either 2.20 or 2.70mm mesh wire and 3.4mm diameter salvage wire along the mesh roll edging. We normally also provide the 2.2mm binding wire for lacing rolls together along the common edge. These mesh rolls have a high tensile strength and can also be provided with steel dowels as required for anchorage into slopes.


Mesh rolls can be effectively used to prevent rockfalls on steep rock slopes, with mesh attached securely to the rock face, you can also use mesh rolls to cover large areas of mattresses. Often mattress lids get in the way during installations, we recommend leaving them out of the way, covering them when the infill and packing is complete.
Roll sizes available – 2metres wide x 50m long (100m2) or 2 x 100



High Strength Hexagonal Wovenmesh Gabion Rolls Rock Netting Fall Protection 0
